7710 Impulse Surge Tester

7710 Impulse Surge Tester

Product Details:

  • Color White
  • Material Aluminium
  • Product Type Surge Tester
  • Usage For Industrial Use
  • Supply Ability : 1000 Unit Per Month
1000.00 - 3000.00 INR/Unit
X

Price And Quantity

  • 1 Unit
  • 1000.00 - 3000.00 INR/Unit

Product Specifications

  • Aluminium
  • Surge Tester
  • For Industrial Use
  • White

Trade Information

  • 1000 Unit Per Month
  • 3 - 4 Week
  • All India

Product Description

High Voltage Surge Tester / High Voltage Impulse Tester

Coils are used in a large spectrum of usages e.g. generator, motor, transformer, ignition coil for motorcycles & cars, relay, filter, electromagnet and varied inductors, almost all the electrical as well as electronic items have to utilize coils. However, coils do not have an absolute automatic production procedure like the existing enameled wires and the standard electronic components are neither defect-free during manufacturing nor ensure 100 per cent quality assured. 7710 High voltage Impulse / Surge Tester is a two-channel 10KV impulse winding device that offers the comparison of waveform functions that is Area under curve ratio, Voltage time difference, Area size ratio and you can utilize the cursor to choose required comparison collection in order to cover all the waveform differences produced by electrical properties then find out a defective parts. This High voltage Impulse Tester offers varied harmonics method and accommodate all types of coils, and become the finest tester that customer are able to search on the market so as to certify coil quality.

Key Features:

  • Lower power pulses test function
  • Low power non-destructive test analysis
  • Automatic Level Control Function (ALC)
  • Waveform learning comparison to achieve rapid test speed
  • 8channels test (7720)
  • Multiple winding test function
  • Interchangeable between Chinese and English operational interfaces
  • Provide statistic and print functions

Measurement Data

Channel

2

Impulse Voltage

200V ~ 10000V

Accuracy

±2%

Measurement time

50mS

Technical Specifications

Power Supply

98 ~ 132Vac or 192 ~ 264Vac

Display

320x240 dot-matrix display

Interface

RS-232, Print port, Remote Control

Flash Memory

200 sets

Operation

Auto、Manual

Environment

Temperature : 10℃ to 40℃ Humidity : 20 ~ 90%

Dimension (W x H x D)

435x133x525 (mm)

Weight

8 (Kg)


Measurement Items

  • Total Area
  • Area size comparison
  • Waveform comparison
  • Flutter
  • Corona

Applications

Include Inverters, Power Inductors, Transformers, Motors, Wave Filters, Capacitors and Wires
